Product Summary
The CA3306CE is a CMOS parallel (FLASH) analog-to-digital converter designed for applications demanding both low power consumption and high speed digitization. Digitizing at 15MHz, for example, requires only about 50mW. The CA3306CE operates over a wide, full scale signal input voltage range of 1V up to the supply voltage. Power consumption is as low as 15mW, depending upon the clock frequency selected. The applications of the CA3306CE include: TV Video Digitizing, Ultrasound Signature Analysis, Transient Signal Analysis, High Energy Physics Research, High Speed Oscilloscope Storage/Display, General Purpose Hybrid ADCs, Optical Character Recognition, Radar Pulse Analysis, Motion Signature Analysis, Robot Vision.
Parametrics
CA3306CE absolute maximum ratings: (1)DC Supply Voltage Range, VDD Voltage Referenced to VSS Terminal: -0.5V to +8.5V; (2)Input Voltage Range All Inputs Except Zener: -0.5V to VDD + 0.5V; (3)DC Input Current CLK, PH, CE1, CE2, VIN: ±20mA.
Features
CA3306CE features: (1)CMOS Low Power with Video Speed (Typ): 70mW; (2)Parallel Conversion Technique; (3)Signal Power Supply Voltage: 3V to 7.5V; (4)15MHz Sampling Rate with Single 5V Supply; (5)6-Bit Latched Three-State Output with Overflow Bit; (6)Pin-for-Pin Retrofit for the CA3300.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 CA3306CE |
Intersil |
IC CONV A/D FLASH 6BIT 18-DIP |
Data Sheet |
Negotiable |
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
|
CA3306C |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
|
CA3306CE |
Intersil |
IC CONV A/D FLASH 6BIT 18-DIP |
Data Sheet |
Negotiable |
|
||||||||||||
|
CA3310 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
|
