ICL7660CBAZ-T

ICL7660CBAZ, CMOS Voltage Converters, Intersil, 10.5V, 99.9%, 8-SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~10.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~10.00

PartNumber:: ICL7660CBAZ-T

Brand:: Intersil Corporation - Intersil | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. jasmine's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-07

From Other Seller

Part Number:ICL7660CBAZ-T
US $0.10 - 10.00
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ICL7660CBAZ-T is a monolithic CMOS power supply circuits which offer unique performance advantages over previously available devices. The ICL7660CBAZ-T performs supply voltage conversion from positive to negative for an input range of 1.5V to 10V, resulting in complementary output voltages of -1.5V to -10V. The applications of the ICL7660CBAZ-T are On Board Negative Supply for Dynamic RAMs, Localized μProcessor (8080 Type) Negative Supplies, Inexpensive Negative Supplies, Data Acquisition Systems

Parametrics

ICL7660CBAZ-T absolute maximum ratings: (1)Supply Voltage: +10.5V; (2)LV and OSC Input Voltage: -0.3V to (V+ +0.3V) for V+ < 5.5V; (Note 2) : (V+ -5.5V) to (V+ +0.3V) for V+ > 5.5V; (3)Current into LV (Note 2): 20μA for V+ > 3.5V; (4)Output Short Duration (VSUPPLY ≤ 5.5V): Continuous.

Features

ICL7660CBAZ-T features: (1)Simple Conversion of +5V Logic Supply to ±5V Supplies; (2)Simple Voltage Multiplication (VOUT = (-) nVIN); (3)Typical Open Circuit Voltage Conversion Efficiency: 99.9%; (4)Typical Power Efficiency: 98%; (5)Wide Operating Voltage Range: 1.5V to 10.0V; (6)ICL7660A 100% Tested at 3V; (7)Easy to Use - Requires Only 2 External Non-Critical Passive Components; (8)No External Diode Over Full Temp. and Voltage Range; (9)Pb-Free Plus Anneal Available (RoHS Compliant).
