Product Summary

The SPA20N60C3 is a cool MOS power transistor.

Parametrics

SPA20N60C3 absolute maximum ratings: (1)Continuous drain current Tc = 25℃: 20.7 A;(2)Continuous drain current Tc = 100℃: 20.7A;(3)Pulsed drain current, tp limited by Tjmax: 62.1 A;(4)Avalanche energy, single pulse: 690 mJ;(5)Avalanche energy, repetitive tAR limited by Tjmax: 1 mJ;(6)Avalanche current, repetitive tAR limited by Tjmax: 20 A;(7)Gate source voltage static: ±20 V;(8)Gate source voltage AC (f >1Hz): ±30 V;(9)Power dissipation, TC = 25℃: 208 or 34.5W;(10)Operating and storage temperature: -55 to +150℃.

Features

SPA20N60C3 features: (1)New revolutionary high voltage technology; (2)Worldwide best RDS(on) in TO 220; (3)Ultra low gate charge; (4)Periodic avalanche rated; (5)Extreme dv/dt rated; (6)High peak current capability; (7)Improved transconductance; (8)P-TO-220-3-31: Fully isolated package (2500 VAC; 1 minute).

Diagrams

SPA20N60C3 diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SPA20N60C3
SPA20N60C3
Infineon Technologies
MOSFET COOL MOS N-CH 600V 20.7A
Data Sheet
0-245: $1.95
245-500: $1.58
500-1000: $1.33
1000-2000: $1.27
